Asus PRIME H610M-R DDR5 LGA1700 Micro-ATX Motherboard

SPECIFICATIONS:

• CPU
• Intel^® Socket LGA1700 for Intel^® Core™ 12th, 14^th & 13^th Gen Processors,Pentium^® Gold and Celeron^® Processors
• Supports up to Intel® 65W CPU
• Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
• Chipset
• Intel® H610 Chipset
• Memory
• 2 x DIMM slots, max. 96GB, DDR5
• 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory
• Dual Channel Memory Architecture
• Supports Intel® Extreme Memory Profile (XMP)
• Graphics
• 1 x DisplayPort
  1 x VGA port
  1 x HDMITM port
• Expansion Slots
• Intel® Core™ Processors (14th & 13th & 12th Gen)
  • 1 x PCIe 4.0 x16 slot
• Intel® H610 Chipset
  • 1 x PCIe 3.0 x1 slot
• Storage
• Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
• Intel® H610 Chipset
• M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
• 4 x SATA 6Gb/s ports
• Ethernet
• 1 x Realtek 1Gb Ethernet
• USB
• Rear USB (Total 4 ports)
  • 2 x USB 3.2 Gen 1(5G) ports (2 x Type-A)
  • 2 x USB 2.0 ports (2 x Type-A)
• Front USB (Total 6 ports)
  • 1 x USB 3.2 Gen 1(5G) header supports additional 2 USB 3.2 Gen 1 ports
  • 2 x USB 2.0 headers support an additional 4 USB 2.0 ports
• USB Ports
• 2 x USB4® (40Gbps) port(s) (2 x USB Type-C®)
• 1 x USB 20Gbps port(s) (1 x USB Type-C®)
• 7 x USB 10Gbps port(s) (7 x Type-A)
• 1 x USB 2.0 port (1 x Type-A)
• 1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD/QC4+)
• 1 x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports
• 3 x USB 2.0 headers support 6 additional USB 2.0 ports
• Audio
• Realtek 7.1 Surround Sound High Definition Audio CODEC
  • Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • Supports up to 24-bit/192 kHz playback
• Audio Features:
  • Audio Shielding
  • Premium audio capacitors
  • Dedicated audio PCB layers
• Back Panel I/O Ports
• 2 x USB 3.2 Gen 1(5G) ports (2 x Type-A)
• 2 x USB 2.0 ports (2 x Type-A)
• 1 x DisplayPort
• 1 x VGA port
• 1 x HDMITM port
• 1 x Realtek 1Gb Ethernet port
• 3 x Audio jacks
• 1 x PS/2 Keyboard (purple) port
• 1 x PS/2 Mouse (green) port
• Internal I/O Connectors
• Fan and Cooling:
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin Chassis Fan header
• Storage-related:
  • 1 x M.2 slot (Key M)
    4 x SATA 6Gb/s ports
• USB:
  • 1 x USB 3.2 Gen 1(5G) header supports additional 2 USB 3.2 Gen 1 ports
  • 2 x USB 2.0 headers support an additional 4 USB 2.0 ports
• Miscellaneous:
  • 1 x Clear CMOS header
  • 1 x Chassis Intrusion header
  • 1 x COM Port header
  • 1 x Front Panel Audio header (AAFP)
  • 1 x LPT header
  • 1 x Speaker header
  • 1 x SPI TPM header (14-1 pin)
  • 1 x 10-1 pin System Panel header
• Special Features
• ASUS 5X PROTECTION III
  • DIGI+ VRM
  • LANGuard
  • Overvoltage Protection
  • SafeSlot Core
  • Stainless-Steel Back I/O
• ASUS Q-Design
  • Q-DIMM
  • Q-Slot
  • Q-LED Core
• ASUS Thermal Solution
  • Aluminium heatsink design
• Software Features
• ASUS Exclusive Software
  • Armoury Crate
  • AI Suite 3
  • EPU
  • DIGI+ VRM
  • PC Cleaner
  • ASUS CPU-Z
  • Norton 360 for Deluxe (60 Days Free Trial)
  • WinRAR
• UEFI BIOS
  • ASUS EZ DIY
  • ASUS CrashFree BIOS 3
  • ASUS EZ Flash 3
  • ASUS UEFI BIOS EZ Mode
• BIOS
• 128 Mb Flash ROM, UEFI AMI BIOS
• Manageability
• WOL by PME, PXE
• Operating System
• Windows® 11 64-bit, Windows® 10 64-bit
• Form Factor
• mATX Form Factor
• Dimensions: 22.6 cm x 19.5 cm

WHAT'S IN THE BOX:

• Asus PRIME H610M-R DDR5 LGA1700 Micro-ATX Motherboard x1
• SATA 6Gb/s cables x2
• I/O Shield x1
• M.2 ANCHOR x1
• User guide x1
